Creating the Database Tables From ER Model

Drawing the Entity-Relationship Diagram

The objective is to develop a simple system for managing customer purchase orders. First, you must identify the business entities involved and their relationships. To do that, you draw an entity-relationship (E-R) diagram by following the rules and examples given in Figure 1-1.

Figure 1-1 Rules for Drawing an E-R Diagram

As Figure 1-2 illustrates, the basic entities in this example are customers, purchase orders, line items, and stock items.

Figure 1-2 E-R Diagram for Purchase Order Application

A Customer has a one-to-many relationship with a Purchase Order because a customer can place many orders, but a given purchase order can be placed by only one customer. The relationship is optional because zero customers might place a given order (it might be placed by someone not previously defined as a customer).

A Purchase Order has a many-to-many relationship with a Stock Item because a purchase order can refer to many stock items, and a stock item can be referred to by many purchase orders. However, you do not know which purchase orders refer to which stock items.

Therefore, you introduce the notion of a Line Item. A Purchase Order has a one-to-many relationship with a Line Item because a purchase order can list many line items, but a given line item can be listed by only one purchase order.

A LineItem has a many-to-one relationship with a StockItem because a line item can refer to only one stock item, but a given stock item can be referred to by many line items. The relationship is optional because zero line items might refer to a given stock item.

Planning the Database Schema

Next, you must devise a schema plan. To do that, you decompose the E-R diagram into the following database tables:

• Customers
• Orders
• LineItems
• StockItems

For example, you assign Customer attributes to columns in the table Customers.

Figure 1-3 depicts the relationships between tables. The E-R diagram showed that a line item has a relationship with a purchase order and with a stock item. In the schema plan, you establish these relationships using primary and foreign keys.

A primary key is a column (or combination of columns) whose values uniquely identify each row in a table. A foreign key is a column (or combination of columns) whose values match the primary key in some other table. For example, column PONo in table LineItems is a foreign key matching the primary key in table Orders. Every purchase order number in column LineItems.PONo must also appear in column Orders.PONo.

Figure 1-3 Schema Plan for Purchase Order Application

Creating the Database Tables

Next, you create the database tables required by the schema plan. You begin by defining the table Customers, as follows:

CREATE TABLE Customers (

  CustNo   NUMBER(3) NOT NULL,

  CustName VARCHAR2(30) NOT NULL,

  Street   VARCHAR2(20) NOT NULL,

  City     VARCHAR2(20) NOT NULL,

  State    CHAR(2) NOT NULL,

  Zip      VARCHAR2(10) NOT NULL,

  Phone    VARCHAR2(12),

  PRIMARY KEY (CustNo)

);

The table Customers stores all the information about customers. Essential information is defined as NOT NULL. For example, every customer must have a shipping address. However, the table Customers does not manage the relationship between a customer and his or her purchase order. So, that relationship must be managed by the table Orders, which you define as:

CREATE TABLE Orders (

  PONo      NUMBER(5),

  Custno    NUMBER(3) REFERENCES Customers,

  OrderDate DATE,

  ShipDate  DATE,

  ToStreet  VARCHAR2(20),

  ToCity    VARCHAR2(20),

  ToState   CHAR(2),

  ToZip     VARCHAR2(10),

  PRIMARY KEY (PONo)

);

The E-R diagram in Figure 1-2 showed that line items have a relationship with purchase orders and stock items. The table LineItems manages these relationships using foreign keys. For example, the foreign key (FK) columnStockNo in the table LineItems references the primary key (PK) column StockNo in the table StockItems, which you define as:

CREATE TABLE StockItems (

  StockNo     NUMBER(4) PRIMARY KEY,

  Description VARCHAR2(20),

  Price       NUMBER(6,2))

);

The table Orders manages the relationship between a customer and purchase order using the FK column CustNo, which references the PK column CustNo in the table Customers. However, the table Orders does not manage the relationship between a purchase order and its line items. So, that relationship must be managed by the table LineItems, which you define as:

CREATE TABLE LineItems (

  LineNo    NUMBER(2),

  PONo      NUMBER(5) REFERENCES Orders,

  StockNo   NUMBER(4) REFERENCES StockItems,

  Quantity  NUMBER(2),

  Discount  NUMBER(4,2),

  PRIMARY KEY (LineNo, PONo)

);

The Entity-Relationship Model

Top of Form

Bottom of Form

Database Design

Goal of design is to generate a formal specification of the database schema

Methodology:

1.     Use E-R model to get a high-level graphical view of essential components of enterprise and how they are related

2.     Then convert E-R diagram to SQL DDL, or whatever database model you are using

E-R Model is not SQL based. It's not limited to any particular DBMS. It is a conceptual and semantic model – captures meanings rather than an actual implementation

The E-R Model: The enterprise is viewed as set of

• Entities
• Relationships among entities

Symbols used in E-R Diagram

• Entity – rectangle
• Attribute – oval


• Relationship – diamond
• Link - line

---

Entities and Attributes

Entity: an object that is involved in the enterprise and that be distinguished from other objects. (not shown in the ER diagram--is an instance)

• Can be person, place, event, object, concept in the real world
• Can be physical object or abstraction
• Ex: "John", "CSE305"

Entity Type: set of similar objects or a category of entities; they are well defined

• A rectangle represents an entity set
• Ex: students, courses
• We often just say "entity" and mean "entity type"

Attribute: describes one aspect of an entity type; usually [and best when] single valued and indivisible (atomic)

• Represented by oval on E-R diagram
• Ex: name, maximum enrollment
• May be multi-valued – use double oval on E-R diagram
• May be composite – attribute has further structure; also use oval for composite attribute, with ovals for components connected to it by lines
• May be derived – a virtual attribute, one that is computable from existing data in the database, use dashed oval. This helps reduce redundancy

---

Entity Types

An entity type is named and is described by set of attributes

• Student: Id, Name, Address, Hobbies

Domain: possible values of an attribute.

• Note that the value for an attribute can be a set or list of values, sometimes called "multi-valued" attributes
• This is in contrast to the pure relational model which requires atomic values
• E.g., (111111, John, 123 Main St, (stamps, coins))

Key: subset of attributes that uniquely identifies an entity (candidate key)

Entity Schema:

The meta-information of entity type name, attributes (and associated domain), key constraints

Entity Types tend to correspond to nouns; attributes are also nouns albeit descriptions of the parts of entities

May have null values for some entity attribute instances – no mapping to domain for those instances

---

Keys

Superkey: an attribute or set of attributes that uniquely identifies an entity--there can be many of these

Composite key: a key requiring more than one attribute

Candidate key: a superkey such that no proper subset of its attributes is also a superkey (minimal superkey – has no unnecessary attributes)

Primary key: the candidate key chosen to be used for identifying entities and accessing records.  Unless otherwise noted "key" means "primary key"

Alternate key: a candidate key not used for primary key

Secondary key: attribute or set of attributes commonly used for accessing records, but not necessarily unique

Foreign key: term used in relational databases (but not in the E-R model) for an attribute that is the primary key of another table and is used to establish a relationship with that table where it appears as an attribute also.

So a foreign key value occurs in the table and again in the other table. This conflicts with the idea that a value is stored only once; the idea that a fact is stored once is not undermined.

---

Graphical Representation in E-R diagram

Rectangle -- Entity

Ellipses -- Attribute (underlined attributes are [part of] the primary key)

Double ellipses -- multi-valued attribute

Dashed ellipses-- derived attribute, e.g. age is derivable from birthdate and current date.

[Drawing notes: keep all attributes above the entity. Lines have no arrows. Use straight lines only]

---

Relationships

Relationship: connects two or more entities into an association/relationship

• "John" majors in "Computer Science"

Relationship Type: set of similar relationships

• Student (entity type) is related to Department (entity type) by MajorsIn (relationship type).

Relationship Types may also have attributes in the E-R model.  When they are mapped to the relational model, the attributes become part of the relation. Represented by a diamond on E-R diagram.

Relationship types can have descriptive attributes like entity sets

Relationships tend to be verbs or verb phrases; attributes of relationships are again nouns

[Drawing tips: relationship diamonds should connect off the left and right points; Dia can label those points with cardinality; use Manhattan connecting line (horizontal/vertical zigzag)]

---

Attributes and Roles

An attribute of a relationship type adds additional information to the relationship

• e.g., "John" majors in "CS" since 2000
• John and CS are related
• 2000 describes the relationship - it's the value of the since attribute of MajorsIn relationship type

The role of a relationship type names one of the related entities. The name of the entity is usually the role name.

e.g., "John" is value of Student role, "CS" value of Department role of MajorsIn relationship type

(John, CS, 2000) describes a relationship

Problem: relationships can relate elements of same entity type

e.g., ReportsTo relationship type relates two elements of Employee entity type:

·         Bob reports to Mary since 2000

We do not have distinct names for the roles. It is not clear who reports to whom.

Solution: the role name of relationship type need not be same as name of entity type from which participants are drawn

• ReportsTo has roles Subordinate and Supervisor and attribute Since
• Values of Subordinate and Supervisor both drawn from entity type Employee

Optional to name role of each entity-relationship, but helpful in cases of

• Recursive relationship – entity set relates to itself
• Multiple relationships between same entity sets

Roles are edges labeled with role names (omitted if role name = name of entity set). Most attributes have been omitted.

---

Relationship Type

Relationship types are described by the set of roles (entities) and [optional] attributes

• e.g., MajorsIn: Student, Department, Since

Think that entities are nouns; relationship types are often verbs

• students and departments are the entities (nouns) and roles in relationship types
• majors is the relationship type (verb)
• i.e., "student" "majors in " "department"

Here we have equate the role name (Student) the name of the entity type (Student) of the participant in the relationship.

---

Degree of relationship

The number of roles in the relationship

Binary – links two entity sets; set of ordered pairs (most common)

Ternary – links three entity sets; ordered triples (rare). If a relationship exists among the three entities, all three must be present

N-ary – links n entity sets; ordered n-tuples (very rare). If a relationship exists among the entities, then all must be present. Cannot represesnt subsets.

Note: ternary relationships may sometimes be replaced by two binary relationships (see book Figures 3.5 and 3.13). Semantic equivalence between ternary relationships and two binary ones are not necessarily true.

---

Cardinality of Relationships

Cardinality is the number of entity instances to which another entity set can map under the relationship. This does not reflect a requirement that an entity has to participate in a relationship. Participation is another concept.

One-to-one: X-Y is 1:1 when each entity in X is associated with at most one entity in Y, and each entity in Y is associated with at most one entity in X.

One-to-many: X-Y is 1:M when each entity in X can be associated with many entities in Y, but each entity in Y is associated with at most one entity in X.

Many-to-many: X:Y is M:M if each entity in X can be associated with many entities in Y, and each entity in Y is associated with many entities in X ("many" =>one or more and sometimes zero)



---

Relationship Participation Constraints

Total participation

• Every member of entity set must participate in the relationship
• Represented by double line from entity rectangle to relationship diamond
• E.g., A Class entity cannot exist unless related to a Faculty member entity in this example, not necessarily at Juniata.
• You can set this double line in Dia
• In a relational model we will use the references clause.

Key constraint

• If every entity participates in exactly one relationship, both a total participation and a key constraint hold
• E.g., if a class is taught by only one faculty member.

Partial participation

• Not every entity instance must participate
• Represented by single line from entity rectangle to relationship diamond
• E.g., A Textbook entity can exist without being related to a Class or vice versa.

---

Existence Dependency and Weak Entities

Existence dependency: Entity Y is existence dependent on entity X is each instance of Y must have a corresponding instance of X

In that case, Y must have total participation in its relationship with X

If Y does not have its own candidate key, Y is called a weak entity, and X is strong entity

Weak entity may have a partial key, called a discriminator, that distinguishes instances of the weak entity that are related to the same strong entity

Use double rectangle for weak entity, with double diamond for relationship connecting it to its associated strong entity

Note: not all existence dependent entities are weak – the lack of a key is essential to definition

---

Schema of a Relationship Type

Contains the following features:

Role names, R_i, and their corresponding entity sets. Roles must be single valued (the number of roles is called its degree)

Attribute names, A_j, and their corresponding domains. Attributes in the E-R model may be set or multi-valued.

Key: Minimum set of roles and attributes that uniquely identify a relationship

Relationship: <e₁, …e_n; a₁, …a_k>

·         e_i is an entity, a value from R_i’s entity set

·         a_j is a set of attribute values with elements from domain of A_j

---

ER Diagram Example
